weight (kg) : 1
MOQ : 100 pieces
Products name : Plunger Type Tool Setter Z Axis Presetter
Motion Position : 0.2-0.5MM
Model 1 : NPN normally open (N0.) (0N at proximity)
Brand Name : Makinopc
machinery test report : Not Available
warranty : 1 Year
Material : Housing/Nut/Shaft:SUS303
Price : $65-75 / piece
Repeatability : 0.001mm
video outgoing-inspection : Provided
Machine Type : Punching Machine, Milling Machine
Contact force : 0.6N
Efforts to contact : 1N
Place of Origin : Guangdong, China
Stroke : 3mm
Rated voltage : DC5-24V
Model 2 : NPN Normally Closed (NC.) (0F at proximity) (Model No. End B)
Product Name | Plunger Type Tool Setter |
Repeatability | 0.001MM |
Stroke | 3MM |
Operating force | 0.6N |
Motion Position | 0.2-0.5MM |
Tolerance | Below 0.1MM |
Power supply voltage | DC5-24V |
Output method | NPN normally open (N0.) (0N at proximity) |
NPN Normally Closed (NC.) (0F at proximity) (Model No. End B) | |
Output airflow | 15mA MAX |
Current consumption | 5mA MAX |
Cable specification | 1M length, N.0: Gray; N.C: Black; Medium 2.8mm |
Withstanding Voltage | AC1000V 1min |
Insulation resistance | DC250V≥20MQ |
Indicator light | Approx. 100mm from main body |
Material | Housing/Nut/Shaft:SUS303 |
Installation | M8 nut mounting pitch 5N,m |
Net Weight | 24g |
Gross Weight | 25g |
Protection class | IP67 equivalent |
Temperature | -20℃~85℃(no condensation) |
Humidity | 20~95%RH |








|
|
CNC Engraving Machine Plunger Type Tool Setter 0.001mm Repeatability 0.6N Operating Z Axis 3mm Stroke SUS303 NO NC Signal Output Images |
